Copper CNC Machining Service
Get high-quality copper CNC machining services with advanced machinery and an experienced team that ensures precision and efficiency. Exceptional results that meet your specifications, whether you need prototypes or large-scale production runs.
Copper in CNC Machining
Copper is a versatile material used in various industries due to its excellent electrical and thermal conductivity, corrosion resistance, and malleability. It is widely used in various electrical applications due to its exceptional thermal and electrical conductivity. Companies in various industries, including electrical, construction, transport, and consumer goods, find the alloy’s versatility and useful properties beneficial for various applications. Raw pieces of metal are meticulously carved down to create the desired shape or object in CNC machined copper parts.
| السبائك المتوفرة | 6061، 6061-T6، 6063، 6082، 5052، 5083، 2024، 7075، 7075-T6، ADC12 |
| السعر | $ |
| المهلة الزمنية | أقل من 10 أيام |
| سُمك الجدار | 0.75 مم |
| التفاوتات المسموح بها | ±0.125 مم (±0.005 بوصة) |
| الحد الأقصى لحجم الجزء | 200 × 80 × 100 سم |
Copper C101(T2)
Copper C103(T1)
Copper C103(TU2)
Copper C110(TU0)
التفاوتات العامة للتشغيل الآلي باستخدام الحاسب الآلي
| الوصف | التسامح العام أو المعيار العام |
|---|---|
| تفاوتات الأبعاد العامة | ±0.005″ (±0.127 mm) for metals; ±0.010″ (±0.254 mm) for plastics in line with ISO 2768-mK unless otherwise specified |
| التفاوتات الضيقة | Down to ±0.001″ (±0.025 mm) available upon request, with detailed 2D drawings and GD&T specifications |
| الحد الأدنى لحجم الميزة | ~0.020″ (0.50 mm), depends on part geometry, tool diameter, and material |
| التفاوت المسموح به لقطر الفتحة | ±0.002″ (±0.05 mm) typical; tighter tolerances with boring or reaming |
| التسطيح/التوازي | ≤0.002″ per 6″ (≤0.05 mm per 150 mm), varies by material and fixture setup |
| التفاوتات اللولبية | سنون لولبية قياسية مترية وإمبراطورية حسب ISO/ASME؛ وتتوفر سنون لولبية مخصصة أو دقيقة عند الطلب |
| التحمل الزاوي | ± 0.5 درجة نموذجي |
| حالة الحافة | تكون الحواف الحادة مكسورة ومطموسة بشكل افتراضي ما لم يُذكر خلاف ذلك |
| تشطيب السطح (قياسي) | Ra 3.2 ميكرومتر (125 ميكرو بوصة) كما هي مُشكّلة؛ وتتوفر تشطيبات محسّنة عن طريق التلميع، والسفع بالخرز والأكسدة، إلخ. |
| الحد الأقصى لحجم الجزء | Milling: Up to 80″ × 48″ × 24″ (2,032 × 1,219 × 610 mm) Turning: Up to 62″ length × 32″ diameter (1,575 × 813 mm) |
Advantages and Limitations of Copper CNC Machining
- High Electrical Conductivity: Ensures minimal energy loss and efficient performance.
- High Thermal Conductivity: Ideal for heat exchangers, radiators, and other thermal management systems.
- مقاومة التآكل: Long-lasting and able to withstand harsh environments.
- Malleability and Ductility: Easily shaped and formed into complex designs.
- Biostatic Properties: Resists bacterial growth and is useful in medical applications.
- المتانة: Long lifespan, reducing the need for frequent replacements.
- Softness: Prone to deformation under stress, challenging to maintain tight tolerances.
- Gummy Nature: Adheres to cutting tools, leading to poor surface finishes and increased tool wear.
- Cost: Higher material and machining costs compared to other metals.
- Thermal Expansion: This can affect dimensional stability during temperature fluctuations.
اجعل تصميماتك تنبض بالحياة مع Elite Mould Tech
استمتع بتجربة التصنيع الآلي الدقيق باستخدام الحاسب الآلي مع Elite Mold Tech. من النماذج الأولية المعقدة إلى الإنتاج على نطاق واسع، نحن مستعدون لتحويل أفكارك إلى واقع ملموس. اتصل بنا اليوم لمناقشة احتياجات مشروعك!
- تبادل الخبرات على نطاق واسع
- توسيع نطاق الوصول إلى السوق
- التكنولوجيا المتقدمة المتكاملة
- فرص الابتكار التعاوني
- حلول موثوقة عند الطلب
- جميع التحميلات آمنة وسرية
Copper CNC Machining FAQs
What is the process for CNC milling copper?
CNC milling copper involves using computer-controlled machinery to remove material from a solid block of copper to create precise parts and components. The process typically includes programming the CNC machine, setting up the copper material, and performing the milling operations with specialized cutting tools.
What are the typical costs associated with CNC machining copper?
The costs can vary depending on factors such as the complexity of the design, the type of copper used, the quantity of parts, and any additional finishing processes required. For a detailed quote, please upload your design file on our quotation platform.
Why is machining copper difficult?
Machining copper can be challenging due to its softness and high ductility. This can cause it to adhere to cutting tools, leading to poor surface finishes and increased tool wear. Specialized tools and techniques are necessary to achieve optimal results.
What tools are used in machining copper?
Tools used in copper machining include high-speed steel (HSS) and carbide tools designed to handle copper’s properties. Additionally, specialized coatings and geometries may enhance tool performance and longevity.
