Skip to content Get instant quotes on custom sheet metal parts with Elite Mold Tech’s Sheet Metal Fabrication Service. We deliver high-quality prototypes and production parts in days, with free standard shipping cost.. Our manufacturing network is ISO 9001:2015, ISO 14001, IATF 16949:2016, and ISO 13485 certified, ensuring compliance with the highest industry standards.
At Elite Mold Tech, we provide fast, reliable sheet metal fabrication tailored for engineers, designers, and manufacturers. Whether you need prototypes or high-volume production, our extensive manufacturing network ensures top-quality results.
Our instant quoting system lets you upload a CAD file to receive real-time pricing and lead times, making the process efficient and seamless. We support a variety of materials, including aluminum, stainless steel, carbon steel, and copper, to meet diverse industry needs.
Sheet metal fabrication is a manufacturing process that shapes flat metal sheets into precise, functional parts using cutting, bending, punching, and welding techniques. Common fabrication methods include laser cutting, CNC punching, press brake forming, and MIG/TIG welding, ensuring accuracy and repeatability.
With computer-aided design (CAD) and CNC-controlled machinery, sheet metal fabrication produces durable, lightweight parts suitable for automotive, aerospace, robotics, medical devices, and industrial equipment applications.
At Elite Mold Tech, we employ a series of advanced techniques to transform raw metal sheets into high-quality finished products. Below is an overview of the key processes involved in our sheet metal fabrication:
Shearing efficiently cuts large metal sheets into smaller, precise pieces with high accuracy.
Punching and bending processes create holes, angles, and customized shapes for metal components.
Trimming and forming refine metal parts, ensuring smooth edges and complex three-dimensional structures.
At Elite Mold Tech, we employ a series of advanced techniques to transform raw metal sheets into high-quality finished products. Below is an overview of the key processes involved in our sheet metal fabrication:
Shearing efficiently cuts large metal sheets into smaller, precise pieces with high accuracy.
Punching and bending processes create holes, angles, and customized shapes for metal components.
Trimming and forming refine metal parts, ensuring smooth edges and complex three-dimensional structures.
Sheet Metal Fabrication Tolerances ensure precision in cutting, bending, and forming processes, maintaining tight tolerances up to ±0.005 inches. Achieve consistent accuracy, optimal fit, and high-quality components for various industrial applications.
| Feature | Description |
|---|---|
| Blank Size | 5’ x 10’ (1.52 m x 3.05 m). We accommodate larger part volumes upon request. |
| Standard Lead Time | 3 business days |
| Sheet Thickness | 0.024” - 0.250” typical. We accommodate thicker or thinner gauges upon request. |
| General Tolerances | See our Sheet Metal manufacturing standards for details on general tolerances. |
| Braking (Hydraulic) | 14′ length |
| Braking (Magnetic) | 6 tons of magnetic pull across the entire beam, 5/8″ minimum reverse bend |
| Punching | 2″ diameter hole capacity, or larger upon request |
| Welding | Welded edges and seams, weldments, and assemblies |
0.02 – 0.24 inches
121.1 inches
±0.004 inches
Up to 760 beats/min
50 x 196.85 inches
±0.004 inches
224,809 pounds-force (lbf)
122.05 inches
±0.004 inches
0.008 – 1.18 inches (By materials)
| Description | Quantity | Use | Brand/Model | Major function | Processing capacity |
|---|---|---|---|---|---|
| numerical Control Shear | 1 | Cutting section | JINFANGYUAN/BLVR6*3000 | Cut to raw materials/ four long products processing | 1.Thickness:0.02 – 0.24 inches；2.Width:121.1 inches; 3.Strokes:18-48hpm; 4.Accuracy:±0.004 inches |
| NCT | 2 | Cutting section | JINFANGYUAN/MT-200&VT-200 | 1.Punching speed: Up to 760 beats/min; 2.For various special processing; 3.On the same product can be processed from a variety of special shapes | 1.Maximum workpiece range: 50 x 196.85 inches; 2.Max thickness: MT200/0.13 inches; VT200/0.25 inches; 3.Hole Accuracy: ±0.004 inches; 4.Secondary positioning accuracy: ±0.004 inches |
| Busbar Punching | 1 | Cutting section | SHANHE/SHCNC-BP | 1.High precision/ high efficiency processing bus copper bar; 2.To complete the hole (hole/ Naga Madokakong)/ cutting and other processing | 1.Punch Force: 112,404 LBF; 2.Hole Accuracy: <±0.004 inches; 3.Maximum sheet (length * width * height): 236.22 x 7.87 x 0.59 inches; 4.No. of Station: 7 |
| Punch Machine | 10 | Forming section | JINFANGYUAN/PR6C100*3100 | 1.All kinds of sheet metal bending forming; 2.All kinds of sheet metal pieces of simple mold | 1.Bending Force: 224,809LBF; 2.Bending Length: 122.05 inches; 3.Backgauge Precision: ±0.004 inches; 4.Processing thickness: 0.008 – 1.18 inches (By materials) |
| Bending Machine | 4 | Forming section | Haeger 618&824/SMART CEC 08 | 1.Hardware riveting (Screws/ nuts…); 2.Automatic feeding system | – |
| Insertion Machine | 4 | Forming section | – | Corner sink hole/Drilling/Deburring/Reaming | – |
| Bench Drill | 5 | Auxiliary section | – | Tapping | – |
| Tapping Machine | 4 | Auxiliary section | – | – | – |
| Machining Center | 1 | Auxiliary section | – | – | – |
| Welding Equipment | 10 | Auxiliary section | – | TIG welding/CO2 shielded welding/Spot Welding | – |
| Wire Drawing Machine | 1 | Auxiliary section | SG1030-WJS | metal surface treatment | Sandpaper models: 80#/180#/220#/280# |
| Assembly Line | 1 | Auxiliary section | – | – | – |
Offer the best solution for prototype manufacturing, considering a wide range of processes, materials, and surface treatments.
Confirm pricing, requirements, and delivery timelines.
Review product manufacturability and requirements promptly, providing engineering assistance as needed.
Initiate the production order, confirming the production and delivery plan.
Conduct quality inspections based on the BOM and original specifications, providing clear photos for shipment approval.
Ensure secure packaging and provide the tracking number after shipment.
Experience precision CNC machining with Elite Mold Tech. From intricate prototypes to large-scale production, we’re ready to bring your ideas to reality. Contact us today to discuss your project needs!
Standard lead times are 3-5 business days,depending on part complexity and order volume.
Yes,we offer powder coating,anodizing,electropolishing,and plating to meet your functional and aesthetic needs.
We can fabricate parts up to 48” x 48”.Larger sizes may be available based on project requirements
Yes,we provide MIG,TIG,and spot welding,along with assembly services for complex parts
We support aluminum,stainless steel,carbon steel,copper,and brass,offering flexibility for various applications.
We follow ISO2768-mK tolerances,holding ± 0.010” for laser cutting and ± 0.020” for bending.Tighter tolerances are available upon request.
